Advantages and Process of Servo Hydraulic Press MachineUpdate：2023-02-27 Hits：236
Servo hydraulic press machine is currently a new generation of environmentally friendly and energy-saving hydraulic press machine. It has high response and high control positioning accuracy. From the appearance, it includes three parts: main engine, hydraulic system and electric control system. The main part of the hydraulic press machine includes hydraulic cylinders, beams, columns and liquid filling devices. The power mechanism is composed of fuel tank, high pressure pump, control system, electric motor, pressure valve, directional valve and so on.
Process of Servo Hydraulic Press Machine
Filling—master cylinder down quickly—compression—pressure holding—pressure relief return—moving platform moves out (another station moves to the working position synchronously)—master cylinder fast down—pressing—pressure holding—moved out of the station, ejecting cylinder ejecting - Pick up - return to discharge - main cylinder pressure relief return - move out of the workbench and move in - the main cylinder quickly goes down to the next cycle.
Performance Advantages of Servo Hydraulic Press Machine
1. Power saving, energy saving and environmental protection: using servo hydraulic presses can save 20%-80% of electric energy compared with ordinary hydraulic presses.
2. Low noise: Servo motors have lower noise than ordinary motors. Adjustable speed, quieter at low speeds.
3. Fast response: The servo motor has high sensitivity and fast response, and the start-up time is only 0.05 seconds.
4. Low temperature performance: The servo hydraulic press has no overflow, so it generates very little heat. No cooling system is required.
5. High-precision positioning function: the servo hydraulic press can be directly positioned, and the pressure position can be set arbitrarily. Especially suitable for pressing processes.
